IC-PPC-VMEb – 6U VME QorIQ SBC with on-board switch and FPGA


The IC-PPC-VMEb, featuring the QorIQ® T2081 (or T1042) processor, offers unparalleled performance to VME legacy applications and provides ruggedised and highly secure solutions.


Superseding Interface Concept’s IC-De6-VMEb, it ensures compatibility with existing equipments while offering increased embedded computing power.


The IC-PPC-VMEb board provides a flexible combination of interfaces offering a highly versatile open platform in a single slot VME to optimise weight, size, power and cost.


One or Two QorIQ® T2081 (1..1,8 GHz or T1042) with:

  • up to 8 GB DDR3-ECC per CPU
  • 128MB SPI Mirrorbit flash (with backup device for recovery)
  • 128/256MB of Mirror Flash per CPU
  • 512KB of nvRAM per CPU
  • Temperature sensors and monitoring per CPU
  • Calendar clock with supercap backup per CPU
  • Elapse Time Counter
  • DC and Thermal monitoring

  • 1*eUSB slot for SSD Disk per CPU

  • 7*GigaEthernet ports
  • 1*L2+ Giga switch (QoS, VLAN, etc.)
  • up to 3*USB2 external ports
  • 1*RS232 and 2*RS422 port per CPU
  • GPIOs

  • VME64x capability (option)
  • One FMC/XMC slots (exclusive):
    • XMC PCIe x4, or
    • HPC connector (for FMC)
  • One PMC/XMC slots:
    • PCI 32/64-bit at 33/66MHz, PCI-X up to 100 MHz
  • PCIe x4
  • IO report compatible with VITA35 P4V2-64ac
  • One Open FPGA for customer applications, offering 4 Serdes and LVDS differential pairs to HPC connector
