IC-GRA-VPX6a – AMD E8860 / Xilinx Kintex-7 Graphic & Processing board

By combining the power of the E8860 GPU and the Xilinx Kintex®-7 FPGA high ratio processing power to consumption with the high communication capabilities of the OpenVPX, the IC-GRA-VPX6a can manage many video flows in a single VPX chassis slot, allowing high cost reduction.

The IC-GRA-VPX6a is designed to mix up-to-date digital video interfaces with still in use legacy standards such as Stanag 3350 (with useful features: external synchronization, Vertical Interface Reference, etc.).

  • 6U VPX
  • AMD Radeon E8860 GPU
  • Xilinx Kintex®-7 FPGA
  • 6 independent display controllers
  • Stanag 3350
  • OpenCL™

  • AMD Radeon E8860
  • 2GB on-chip GDDR5 memory (1GHz 128-bit)
  • 6 independent display controllers

  • Xilinx Kintex-7 325T
  • 1 GByte DDR3 SDRAM memory bank
  • 1 user SPI Flash Eeprom

  • One PCIe x8 port to P1, One PCIe x4 port to P2
  • One PCIe x8 port to GPU, One PCIe x4 port to FPGA
  • One PCIe x8 port to optional XMC (or PCI-X PMC)

  • PIC μ-controller for System Management (VITA 46.11)
  • Power supply monitoring / Temperature sensor…
  • Status LEDs
  • Engineering kit for debug: JTAG/COP…
  • 6U Rear Transition Module
