IC-INT-VPX6g – 6U VPX Dual Intel Xeon D and FPGA SBC
The IC-INT-VPX6g is a 6U VPX Single Board Computer (SBC) with a dual processing node and an on-board FPGA. Powered by Intel®’s 14nm Xeon®D processor technology and operating within the umbrella of the OpenVPX standard, the IC-INT-VPX6g is a comprehensive dual-processor design for applications requiring the highest processing capabilities with a controlled power consumption.
Combined with Interface Concept VPX 6U Ethernet switches (ComEth products) and FPGA boards (IC-FEP products), the IC-INT-VPX6g provides integrators with the ideal Digital Signal Processing (DSP) board to build High Performance Computers.
- 2* Intel Xeon® D-1539 or D-1559
- D-1539: 8-core 45 W @ 1,60 GHz
- D-1559: 12-core 35 W @ 1,50 GHz
- 64 GB DDR4 with ECC per node
- 32 GB SLC SSD SATA
- 4* SATA Gen3 ports [RB_P5 and P6]
- 4* USB2 ports [RB_P2, P4, P5 and P6]
- 8* GPIOs [RB_P2 and P4]
- PCIe x4 Gen3 to CPU-A (Pn5)
- (Pn6) X12d + X8d to RB_P6 (VITA 46.9)
- (Pn6) X4d to RB_P4, X9s to RB_P5,P6
- 16 LVDS pairs [RB_P3]
- 4 MGTs [RB_P4]
- 512MB DDR3L
- 512Kb NVSRAM
- 2*40GBase-KR4 (rear P1A, P1B) from CPU-B
- 2*40GBase-KR4 (rear P1C, P1D) from CPU-A
- Other configurations possible :
- 4*+ 4* 10GBase-KR
- 2*+ 2* 10GBase-KX4
- 4*+ 4* 1GBase-KX
- ….
- 2*1000Base-KX [RB_P4] (one per CPU)
- 2*10/100/1000Base-T[RB_P4] (one per CPU)
- 4 lanes on [RB_P2B] (from CPU-A)
- 4 lanes on [RB_P2A] (from CPU-B)
