IC-GIGA-XMCb – Gigabit Ethernet XMC module


The IC-GIGA-XMCb is an XMC module providing up to four 10/100/1000 Ethernet channels.

The on-board PCI Express Switch allows to access to the four Intel I210 Gigabit Ethernet controllers available via front panel RJ45 connectors.


  • PCI Express interface
    • 1* PCIe x4 2.5GT/s or 5.0GT/s to Pn5
  • Ethernet interfaces
    • 4* 10/100/1000 BASE-T to RJ45 connector (4* Intel I210IT controllers)
  • 10, 100 and 1000 Mbit/s transmission rates are supported for full or half duplex operation.
